DMS 5 Axis CNC Router 16×60 Gantry E786 [SOLD]

SOLD: DMS 5 axis CNC router, 16 x 60 ft. gantry, 8 ft. stroke, 6 hp HSD ES779 spindle, 12-position ATC rack, Fagor 8065-M Power..

SOLD: This 2022 DMS 5 axis CNC router features a 16 ft. x 60 ft. work space, 8 ft. of Z-axis stroke, 16 hp HSD ES779 ATC spindle motor, and a 12-position automatic tool change rack. CNC router machinery is controlled by a Fagor 8065 CNC system with wireless teach pendant.

Used CNC Router Machine Specifications

  • DMS Mammoth 5-axis gantry CNC router w/ side-wall
  • Originally manufactured in 2022 by Diversified Machine Systems
  • 16 ft. x 60 ft. work space
  • 8 ft. Z-axis stroke, driven by recirculating ball screw assembly
  • 16.1 hp / 12 kW HSD ES779 ATC spindle, HSK 63F, 24,000 RPM
  • 12 position sliding tool rack
  • Continuous C for >12 H. spindle roll over
  • Fagor AC digital Sercos drive system
  • Fagor 8065 M Power CNC system controller
  • Wireless teach pendant
  • DMS tool height sensor
  • Ionized air blast
  • Auto lube
  • 2,000 BTU Air Conditioner
  • 380 – 480 V / 3 PH, 50 / 60 hz power
  • 10 CFM at 95 PSI air requirements
  • Safety light tower

Fagor 8065 M Power CNC System Features

  • 10.4″ LCD monitor
  • Windows 10 Quad-Core processor
  • 4 GB Ram Memory
  • 7.3 GB NAND flash memory
  • Fast card skit
  • 0.25 ms block processing time
  • EtherCAT
  • USB 3.0
  • Ethernet
  • 3D Graphics
  • Canned Cycles
  • RTCP
  • Tangential control
  • Probing Cycles
  • High Speed Surface Accuracy machine system
  • Dynamic Override System
