Used Motionmaster 5 Axis CNC Router E764 [SOLD]

SOLD: 2003 Motionmaster 5 axis CNC router, equipped with a 8 ft. x 16 ft. table, 48 inches of Z axis stroke, alpha gear head, 14 hp Colombo automatic tool change HSK-63F spindle motor. Used CNC machinery is controlled by Fagor 8055 Power CNC system and includes remote teach pendant.

Used CNC Router Machine Specifications

Motionmaster CNC router
Originally manufactured in 2003
5 axis CNC router machinery
8 x 16 ft. gantry
48 inches of Z-axis stroke
Fagor 8055 Power controller
- Ethernet
- TCP
- Tool Radius Compensation
- Telediagnosis
Teach pendant
Alpha gear head
14 hp ATC Colombo spindle motor, HSK-63F
CNCPD reference #E764

Scope of Work done in 2019 by our team

Full Rewire (including monitor/keypad interface)
Modify roller enclosure (cut enclosure in half and attach mounting plate to backside)
Mount modified controller enclosure off the floor to the back of the bridge
Install new remote (hpg) interface on column (VFD) enclosure
Replace wire track from floor junction box to column
Run seal tight from pedestal thru J-box to main enclosure
Replace conduits for gantry motors and limit switches
Move components from backside of enclosure to new location
5 axis head alignment
