GA50U2082ABA Yaskawa GA500 VFD 25 hp 18.6 kW 240 V
The Yaskawa GA50U2082ABA is a heavy-duty 25 HP (18.6 kW) standard-frequency AC drive. Running on 240V 3-phase power, it delivers 75 Amps Heavy Duty and operates at output frequencies up to 590 Hz.
This VFD come with CNC Parts Dept’s easy setup guide. Alternately for a small fee, we can pre-program your drive to match your spindle motor. Ask us about our VFD programming services.
Description
The Yaskawa GA50U2082ABA is a robust and high-capacity choice in the 240 V standard-frequency GA500 class. Designed to handle frequencies up to 590 Hz, this high-performance AC microdrive is optimized to run large industrial synchronous PM and induction motors used in heavy raw-material processing, metal forming, and multi-axis CNC machinery.
Operating on 200–240 V 3-phase power, this model delivers 25 HP (18.6 kW) in Heavy Duty continuous operation, providing 75 Amps of continuous current. Its highly efficient thermal architecture and 150% overload protection guarantee continuous performance under fluctuating load profiles.
Additional information
| Manufacturer | Yaskawa |
|---|---|
| Part Number (MPN) | GA50U2082ABA |
| Model Series | |
| Horsepower (hp) | 25 |
| Kilowatt (kW) | 18.6 |
| Voltage (V) | 200-240 |
| Current (Amps) | 75 |
| Output Frequency (Hz) | 590 |
| Condition | New |
Key Performance & Architectural Advantages
Standard Frequency Speed Profile
Broad standard-frequency output ranges support speed-machining and motor-drive operations up to 590 Hz without sacrificing motor torque efficiency or thermal performance across all load profiles.
Universal Motor Control
Supports advanced sensorless open-loop vector, EZ Vector, PM motor tracking, and traditional V/f control for highly adaptive operation across standard spindle and standard induction motor designs.
Embedded DriveWorksEZ
Customize specific VFD logic operations and automate auxiliary controls without an external PLC by utilizing built-in icon-based software programming environments.
Integrated Braking Transistor
Offers direct dynamic braking torque capability out of the box to rapidly slow and stop standard routing and milling spindles safely (requires external resistors).
Coated PCB Protection
Standard dual-conformally coated printed circuit boards provide robust resistance to conductive metal fragments, carbon wood dust, and humid cooling mist atmospheres.
24 VDC Auxiliary Control Power
Directly powers internal control logic loops and connected external system sensors without requiring a secondary auxiliary cabinet power supply unit.
