824-110-C100-BI RC 110/22 Colombo Spindle Motor

Giordano Colombo

$5,356.00

Giordano Colombo RC110/22 series ER 32 collet spindle motor, double-ended shaft, MTC (Manual tool change), fan-cooled, 10 hp / 7.5 kW, 380 V.

04616 Techniks ER 32 Slotted Nut Wrench

Techniks 04616 ER 32 slotted nut wrench, UM or RU nut type, 253mm x 75mm.

Request More Information

CNC Router Part Request

For a fast and easy CNC router part request, send us a message using the form provided.

Product Description

Giordano Colombo RC series electric spindle motor, Colombo RC 110/22 FP1 BI CPE 32, double-ended, MTC (manual tool change), ER 32, 10 hp / 7.5 kW, 380 V, 18,000 – 24,000 RPM max speed, 300 / 400 Hz, 28.5A, ceramic bearings.

Additional Information

Weight 48 lbs
Dimensions 20 × 8 × 8 in
Brand

Giordano Colombo

Model

S11C002-10BI,3

Condition

New

Voltage

380 V

Power

7.5 kW, 10 hp

Speed

18,000 RPM, 24,000 RPM

Cooling Method

Fan Cooled

Tool Change

Amps

17 Amps

MPN

824-110-C100-BI, S11C002-10BI-3

Manufacturer

Giordano Colombo

Country/Region of Manufacture

Italy

Poles

2

Max Tool Diameter

3/4"

Collet size

ER 32

ER 32 Collets and Collet Nuts

Spindle Motor Lead Time & Availability

Spindle motor lead time and availability varies up to a year. In stock motors can ship within a day or two. Out of stock motor lead times can vary from 4-6 weeks to 6-9 months or longer. We recommend keeping a spare CNC spindle motor on the shelf to avoid costly downtime.

Colombo RC Series Spindle Motors – Compressed Air Cooling

Giordano Colombo spindles are designed for applications on machines working wood, plastic, aluminum, light alloy, glass and marble. The frame is made from extruded aluminum bar or from heat treated special alloy aluminum ingot. The bearings are a precision angular contact type, with steel or ceramic balls and life lubrication with special grease for high speeds.
