GMR3340-27-12401410-348A Glentek Servo Motor

Glentek

$3,250.00

Glentek GMR3300 series DC brush servo motor, model GMR3340-27, 1,000 count encoder, 24 V brake, square flange, 14-Pin connector, no shaft seal.

Out of stock

Request More Information

CNC Router Part Request

For a fast and easy CNC router part request, send us a message using the form provided.

SKU: GMR3340-27-12401410-348A Category: Tags: , Brand:

Product Description

GMR3340-27 Glentek GMR3300 series DC brush servo motor.

Glentek GMR3340-27-12401410-348A Specifications

  • Glentek GMR3300 Series
  • 3.3 inch Diameter
  • 7V Tach
  • 1000 count encoder
  • 24 V brake
  • Square flange
  • 14-Pin wired special connector
  • no shaft seal

CNC Services Tip: This motor replaces obsolete Baldor model MTEB-3363-BLBCN.

Additional Information

Weight 16 lbs
Dimensions 16 × 11 × 10 in
Brand

Glentek

MPN

GMR3340-27-12401410-348A

Model

GMR3340-27, GMR3340-27-12401410-348A

Condition

New

Manufacturer

Glentek

Connection type

MS (military style)

Glentek GMR Series DC Brush Servo Motors

GMR series DC brush servo motors utilize high-energy Neodymium-Iron-Boron (NdFeB) magnets, which provide more torque in a smaller package with higher dynamic performance than traditional ferrite magnet designs. Due to the high torque to inertia ratio of these motors, they are ideal for applications which require high acceleration and deceleration characteristics or where the physical size of the motor is a major concern.

  • Continuous Torque Range: 16.0 Lb-in (1.81 Nm) to 65.0 Lb-in (7.34 Nm)
  • Peak Torque Range: 80.0 Lb-in (9.04 Nm) to 325.0 Lb-in (36.72 Nm)


Glentek GM/GMR Series Servo Motors

Glentek’s DC brush servo motor line features high performance, skewed armatures, and TENV construction. Industry standard mounting, feedback, sealing, and lead termination options available, along with optional fail safe brakes.
